Applicable Welding Methods
  • PLASMA Seam Welding
  • PLASMA Brazing
  • PLASMA Coating
Range of suitable material thickness (Plasma seam welding)~ 0.1 – 1 mm
Automation
  • Capable for automation
Operating modesDC
Supply Voltage230 V ±15 % 50/60Hz
Phase1 Phase
Power connectionGardy plug, 2.5 mm²
Max. welding current at 35 % duty cycle (40 °C)50 A
Max. welding current at 100 % duty cycle (40 °C)30 A
Adjustment range welding current0.2 – 50 A
Max. pilot current at 35 % duty cycle (40 °C)15 A
Max. pilot current at 100 % duty cycle (40 °C)15 A
Adjustment range pilot current0.5 – 15 A
Adjustment range TIG mode0.5 – 50 A
CoolingLiquid
Degree of protectionIP 21 S
Length620 mm
Width300 mm
Height555 mm
Weight47 kg
Features
  • Power source with HF-ignition
  • USB interface
  • Ethernet interface
  • Integrated welding program memory
  • Integrated cooling
  • Integrated monitoring / gaging of cooling medium
  • Integrated electronic gas regulation (PGR)

    electr. plasma control, range 0,1 – 5 l/min

  • Integrated automation interface
  • Software for external controlling via computer
    (diagnostics, parameter setup, documentation)
  • Flowmeter plasma gas
  • Flowmeter shielding gas
  • Remote Control RC-S
  • Foot control of the current
  • Touch Screen 5,4"
Digital Inputs2 × 24 V
Digital Outputs3 × 24 V
Analog Inputs2 × 0 – 10 V
Analog Outputs1 × 0 – 5 V / 1 × 0 – 10 V
Capability for / availability of specific bus interfaces
  • Included
